Modern Design Geocell for Customizable Gravel Stabilization on Highways and Driveways

Name: Modern Design Geocell for Customizable Gravel Stabilization on Highways and Driveways
Brand: Taian Tenglu Engineering Materials Co., Ltd.
SKU: TLSHI01
Price: Negotiable USD
Availability: InStock

Product Details

Place of Origin: Shandong, China

Brand Name: TENGLU

Model Number: TLSHI01

Payment & Shipping Terms

Minimum Order Quantity: 500 square meters

Price: $1.2-3.2

Get Best Price

Product Details

Product Description

Highlight:

Type:	Geocells	Warranty:	More Than 5 Years
After-sale Service:	Online Technical Support, Onsite Installation, Onsite Training, Onsite Inspection, Free Spare Parts, Return And Replacement, Other	Project Solution Capability:	Graphic Design, 3D Model Design, Total Solution For Projects, Cross Categories Consolidation, NONE
Application:	Road Basement,steep Slope,landslide	Design Style:	Modern
Product Name:	Geocell Gravel Grid	Raw Material:	Strengthen HDPE
Color:	Black Green Tan White	Thickness:	1.1mm-1.6mm
Height:	50mm~250mm	Welding Distance:	330mm-1000mm
Certifications:	CE ISO14001 ISO9001	MOQ:	500 Square Meter
Function:	Steep Slope Protection Reinforcement

Type:	Geocells
Warranty:	More Than 5 Years
After-sale Service:	Online Technical Support, Onsite Installation, Onsite Training, Onsite Inspection, Free Spare Parts, Return And Replacement, Other
Project Solution Capability:	Graphic Design, 3D Model Design, Total Solution For Projects, Cross Categories Consolidation, NONE
Application:	Road Basement,steep Slope,landslide
Design Style:	Modern
Product Name:	Geocell Gravel Grid
Raw Material:	Strengthen HDPE
Color:	Black Green Tan White
Thickness:	1.1mm-1.6mm
Height:	50mm~250mm
Welding Distance:	330mm-1000mm
Certifications:	CE ISO14001 ISO9001
MOQ:	500 Square Meter
Function:	Steep Slope Protection Reinforcement

Modern Design Geocell for Customizable Gravel Stabilization on Highways and Driveways

Product Customized

Basic Performance Requirements of Geocell

No.	Item	Unit	PP Material	PE Material
1	Environmental Stress Cracking F50	h	-	≥800
2	Embrittlement Temperature	℃	≤-23	≤-50
3	Vicat Softening Temperature	℃	≥142	≥112
4	Oxidation Induction Time	min	≥20	≥20

Size Deviation of Geocell

No.	Geocell Height(H/mm)			Plate Thickness of Geocell(T/mm)	Weling Distance(A/mm)
No.		Nominal Value	Deviation	Nominal Value	Nominal Value	Deviation
1	H≤100	±1	≥1.1	330≤A＜800	±15
2	100＜H≤200	±2	≥1.1	330≤A＜800	±15

Skills Requirement of Geocell

No.	Testing Item			Unit	PP Geocell	PE Geocell
1	Outlook				the geocell plate should be flat.non-bubble and non-groove mark
2	Tensile Strength of Geocell Plate			Mpa	≥23.0	≥20.0
3	Tensile Strength In Welding Position			N/cm	≥100	≥100
4	Connection Place Of Geocell Group	Edge of Geocell Plate	N/cm	≥200	≥200
5	Connection Place Of Geocell Group		Middle of Geocell Plate	N/cm	≥120	≥120

Advantages

texture of material:high-density polyethylene

Color: black、green、gray

Certificate

Packing Method

Why choose us

Available in a variety of cell sizes, depths, section lengths, and facade colors to suit the project's needs.

Geocell gives strong protection to the impervious layer. It Provides significant subclass deformation without loss of structural integrity.

Transportation and installation of geocell are easy. High resistance to tensile stress, tearing, punching, fatigue.

Geocell is an environmentally friendly material.

Geocells are lightweight, cheap, and have high durability. Compared to other products, the use of geocell is very economical. They
increase the reliability of the structure and structure’s life span. They help to form embankments on poor load-bearing soil. They
help to form earth retention walls and soil sound-absorbing structures.

Factory Tour

Tai'an Tenglu Engineering Materials Co.,Ltd. specializes in the production of geosynthetics such as geomembrane, geotextile, geogrid, geocell, geonet cement blanket,geosynthetic clay liner, 3D composite drainage geonet, plastic drainage board, permeable pipe and other series of geosynthetics.

FAQ

Q1: Are you trading company or manufacturer? A:We are officially licensed MANUFACTURER specializing in the research, production and supplying of geosynthetics with 20 years experience Q2: How about the quality of your products? A: We have professional and advanced brand machine production line and quality control center. Each batch of products will be sampled before package and there also has final inspection before shipment Q3: Can you provide sample? A:Yes,we can offer free samples of some items for quality evaluation. Q4: Can you accept small order? A: Yes.Our minimum order quantity is 1000㎡ Q5: Do you accept customized design order? A: Yes.We welcome customized design orders Q6: What is your lead time? A:General within 7-15 days, large order can be negotiated Q7: What's your delivery term? A: We can accept EXW, FOB, CIF etc (follow customers' request) Q8. What is the payment way? A: Online Bank Payment，T/T,L/C,D/P D/A,PayPal,Western Union
